Main Specification
Rating: DC 12V 20mA
Contact Resistance: ≤50MΩ
Insulation Resistance: ≥100MΩ
Dielectric Strength: AC 250V 1 minute
Operating Force: 180±50gf or 250±50gf
Life: 50,000 cycles
