Specification
Rating: 6A 125/250VAC, 10,000CYCLES
Operating Temperature:  -25 - +85℃
Insulation Resistance: 100MΩ
Dielectric Strength: 1500VAC for 60 +/- 5 sec
Housing: UL94V0
Travel-to-lock: 3.0mm(Total travel: 4.5mm)
Proof  Tracking Index: PTI-250V
Moving Contacts: Silver alloy
Safety approvals: VDE, CE
Operating Force: 560 +/- 150gf  650 +/- 150gf  800 +/- 150gf (we can make it as user requirement)
